ST100U (White)
| STRUCTURE | |||
| Total thickness | 0.9mm | ||
| No. of plies | 1 | ||
| Fabric | Polyester | ||
| Weft | Non-rigid | ||
| Weight | 1kg/m2 | ||
| Constant temp. min | -20°C | ||
| Constant temp. max. | +80° C |
| 1. Top cover | |||
| Top cover thickness | 0.2mm | ||
| Material | Polyurethane | ||
| Colour | White | ||
| Surface | Gloss | ||
| Hardness | 87 shore A |
| 2. Bottom cover | |||
| Material | Fabric | ||
| Colour | Natural | ||
| Surface | Polyester |
| TENSIONS | |||
| Working load 1% elongation | 9N/mm |
| MIN. DRUM DIAMETER | |||
| Flexing | 10mm | ||
| Back Flexing | 15mm |
| JOIN TYPE | |||
| G00SS, Finger splice |
| PROFILES APPLICATION | |||
| Profile on top Cover | Yes | ||
| Profile on bottom cover | Yes |
| SPECIAL CHARACTERISTICS | |||
| Oils Resistant | Yes | ||
| Grease Resistant | Yes | ||
| Flame retardant | No | ||
| Abrasion Resistant | Yes | ||
| FDA Approved | Yes | ||
| 10/2011/EC + amendments | Yes | ||
| Suitable for Curve Conveyors | Yes |
| SUPPORT SURFACE | |||
| Slider bed | Yes | ||
| Rollers | Yes | ||
| Troughed Application | Yes |
| COEFFICIENT OF FRICTION | |||
| Steel driving pulley | 0.15 |
